Function Test Systems

The stimulating one.

These specialist Automeg models test the function and integrity of wiring harnesses combined with active components such as relays, switches, contactors, diodes, LEDS, actuators and other active components.

Create function test programs in minutes.

Take the complex and long task of creating functional tests away from the test engineer, by creating them automatically.  Using your existing ECAD data, our component library and automated software routines, all the different routes and subtests are automatically calculated in seconds by our MKAT software.
More about MKAT software
MKAT existing user banner image

Power up your Automeg with these function test features:

Flexible, powerful stimulation

Stimulus mode available up to 250V AC, 220V DC maximum voltage.  Two additional stimulus buses can be set to all test points for functional testing.

Multiple measurement formats

'E' models are Automeg systems designed for entry level function testing.  This model is ideal if active component density is low or your designs are stable.

'M' Automeg models offer multibus function testing.  They have the highest level of flexibility, with both 2 and 4 wire measurements and function testing.

APG even for functional testing

Active APG (Automatic Program Generation) toolset does all the work for you, even with complex assemblies including active components.

Simply import your component library, netlists, wiring lists and wire schedules to automatically create function test programs.

Read about Automeg's features and toolsets

Get things moving (or lighting up) with function test systems designed for your business.

Your test spec and application are uniquely yours, but we've probably made a system for something similar.  Common function test applications are shown here, amassed from our customer base of over 30 years.
More function applications
Vehicle Cabs
Vehicle Cabs

Vehicle cab function testing Our 'Multibus' function test systems enable you to perform Final Assembly Line testing on your vehicles, whether it's a tractor, earth mover, bus, truck or train.

Our systems not only enable complete testing, so you can compare results over time, but also enable you to make sure all options are present and that they all work.

Customers include MAN Trucks & Daimler Truck. They have typically seen significant time reductions by integrating Automeg function testing into their test procedures.

Door Systems
Active Assemblies
2.7 Function test systems Customer logo 1 Alstom
CAF_logo
daimler_truck_logo
2.7 Function test systems Customer logo 4 MAN Truck and Bus
Motherson logo
Ventura Systems logo

"The D1500 test systems [with functional testing] are an impressive part of our factory.  The integration was a step forward within quality improvement of Ventura Systems."

Gerrit Visser, Project Leader

Ventura Systems

"The greatest strength of the M2000 is the flexibility it provides.  Powering any test point from the PSU means the set up is easier and requires less detailed planning."

Nathan Bramson, Test Engineer

Motherson

Keep functioning, with ongoing service and support.

Whether you prefer the DIY approach or need some hands-on support, we help you get the best from your Automeg function tester.  Our resources library contains product manuals, FAQs, 'how to' guides, and more to help you help yourself.
Alternatively, you can raise a support ticket, browse training and webinars, and request a quote for our service options.
We help you test your best.
Browse support options
Function test cab test hero image

Get more than just a functioning knowledge of our systems with these articles:

View over a person in businesswear looking at a computer monitor. The computer monitor is showing the APG configuration screen within MKAT test management software.

What is the APG in MK Test’s MKAT software?

Inside the MK Test Systems manufacturing facility. Several Automeg test systems are shown in various stages of being built.

How to choose a test system specification

A production technican at a train manufacturing plant is operating a test system whilst giving a 'thumbs up' hand gesture

Automatic program generation improves testing for train OEMs

Want to get functioning more efficiently? Contact us to request a quote, demo or more details.

Please enter your name.
Please enter a valid email address.
Please type your message.
Submit form

Looking for more resources on our function test systems? Head to the library.

From user manuals and technical guides to case studies and FAQs, our resources will help you make the most of your testing processes.

Visit the library
